Triumph (1970-79) Deluxe Belt Drive Crankcase Breather Kit

Triumph Deluxe Belt Drive Crankcase Breather Kit

This kit is designed specifically to work with our belt drive kit. It includes everything you need to let your crankcase breath properly, while limiting the oily mess usually associated with other breathers.

Includes:

• Heavy-duty, alloy, one-way reed valve breather
• Barbed fitting designed to screw into crankcase timing plug
• Clear tubing
• Cable Ties to clamp and secure tubes

Fits:

• 1970-79 Triumph 650 and 750cc Twins, including T120/T140 Bonneville, TR6 Tiger/Trophy and TR7RV Tiger

Installation Note:  Install the breather so that the direction of flow is out of the crankcase.  The side with the lip on the fitting is the intake (exits reed box at 90-degree angle) The fitting exiting the back of the reed box (with no lip) is the exhaust. The can be tested by blowing into the fittings.  If you blow on the end, and air passes, this is the intake. If you blow on an end, and air is blocked by the reed, this is the exhaust.
